exmweb.com | 1-800-363-2423 | [email protected] 12-13 DISCONNECT4809500 U2DSSSECTION A-ALIGHT BRACKETDCEMOUNTINGBRACKETL2.000PANELB7.3753.0003.5001.375REMOVABLECENTER POSTA1.375 EYEBOLTSFAACSTAINLESS STEELPADLOCKABLEHANDLECATALOG NUMBER A B C D E FDIMENSIONS SHIP WGHT LBS.9500 U2DSS725418 72 53.75 18 60 48 11.875 742 9500 U2DSS726618 72 65.75 18 60 60 11.875 894 9500 U2DSS727818 72 77.75 18 60 72 11.875 1027 9500 U2DSS847818 84 77.75 18 72 72 17.875 1110 9500 U2DSS907818 90 77.75 18 78 72 20.875 1196 9500 U2DSS907820 90 77.75 20 78 72 20.875 1286 9500 U2DSS727824 72 77.75 24 60 72 11.875 1190 9500 U2DSS847824 84 77.75 24 72 72 17.875 1265 9500 U2DSS907824 90 77.75 24 78 72 20.875 1343%u2020 For stainless steel type 316, add suffix %u20186%u2019 to the catalog number (ie. 9500 U2DSS7254186). %u2021 For painted stainless steel, add suffix %u2018P%u2019 to the catalog number (ie. 9500 U2DSS725418P). * For Allen Bradley Bulletin 1494F and 1494D disconnect switch piercings, add suffix %u2018AB%u2019 to the catalog number. p.644 p.642 p.624 p.616 p.646 p.626 p.631STAINLESS STEEL MULTI-DOOR DISCONNECT ENCLOSURES
