53NEMA 12-13 MTRX CABINETSSOLID HINGED TOP6500 MXTDDATA SUBJECT TO CHANGE WITHOUT NOTICE.The 6500 MXTD solid top door is made to be installed on top of a Mtrx cabinet. They are made of steel. The 6500 MXTD consists of a hinged solid top cover and installation hardware. The solid top door allows for easy access from the top of the cabinet by unlocking the 1/4 turn locks. A quality, robotically poured-inplace gasket ensures a complete and durable seal. The tops are finished with heat fused polyester powder, electrostatically applied on a phosphatized base. Finish is RAL 7011 sandtex dark gray.BA A - 260.1mm Ap.124 p.125Lifting AnglesCATALOG NUMBERDIMENSIONSW D A BNOMINAL DIMENSIONSW D A BCATALOG NOMINALNUMBER6500 MXTD0809 6500 MXTD0810 6500 MXTD0812 6500 MXTD0904 6500 MXTD0905 6500 MXTD0906 6500 MXTD0908 6500 MXTD1004 6500 MXTD1005 6500 MXTD1006 6500 MXTD1008 6500 MXTD1204 6500 MXTD1205 6500 MXTD1206 6500 MXTD1208 6500 MXTD1604 6500 MXTD1605 6500 MXTD1606 6500 MXTD1608 6500 MXTD1805 6500 MXTD1806 800 900 800 1000 800 1200 900 400 900 500 900 600 900 800 1000 400 1000 500 1000 600 1000 800 1200 400 1200 500 1200 600 1200 800 1600 400 1600 500 1600 600 1600 800 1800 500 1800 600 798 898 798 998 798 1198 898 398 898 498 898 598 898 798 998 398 998 498 998 598 998 798 1198 398 1198 498 1198 598 1198 798 1598 398 1598 498 1598 598 1598 798 1798 498 1798 598 6500 MXTD0404 6500 MXTD0405 6500 MXTD0406 6500 MXTD0408 6500 MXTD0604 6500 MXTD0605 6500 MXTD0606 6500 MXTD0608 6500 MXTD0609 6500 MXTD0610 6500 MXTD0612 6500 MXTD0704 6500 MXTD0705 6500 MXTD0706 6500 MXTD0708 6500 MXTD0709 6500 MXTD0710 6500 MXTD0712 6500 MXTD0804 6500 MXTD0805 6500 MXTD0806 6500 MXTD0808 400 400 400 500 400 600 400 800 600 400 600 500 600 600 600 800 600 900 600 1000 600 1200 700 400 700 500 700 600 700 800 700 900 700 1000 700 1200 800 400 800 500 800 600 800 800 398 398 398 498 398 598 398 798 598 398 598 498 598 598 598 798 598 898 598 998 598 1198 698 398 698 498 698 598 698 798 698 898 698 998 698 1198 798 398 798 498 798 598 798 798 p.646
