p.600 p.628 p.628 p.592 p.617 p.225exmweb.com | 1-800-363-2423 | [email protected] DISTRIBUTION 1412 BSSP / TSSPSPLITTER BOXES & TROUGHS EEMAC/NEMA 4X.625%u201d.625%u201d%u201d .625%u201d.625%u201dThe 1412 BSSP & TSSP powder coated stainless steel troughs are designed for 600 V (max.) service, 3 or 4 wires, in ordinary locations. CSA Certified / NEMA / EEMAC 4X / IP66 Technical specifications:%u2022 Made of high quality stainless steel. %u2022 They have four mounting holes and a screw cover. %u2022 There is a curled lip around all sides to increase rigidity and prevent water from ente ring the enclosure when it is open. %u2022 There are no knockouts. %u2022 The phenolic insulated splitter blocks are factory installed on an interior panel, which is mounted on welded studs. %u2022 The enclosure%u2019s exterior is powder coated ANSI/ASA 61 smooth gray. %u2022 Inner panel is galvanized (other colors available).CATALOG NUMBERA B CDIMENSIONS SHIP WGHT LBS. 3 WIRES 4 WIRES QTY WIRESMAX AMP. CU-AL1412 BSSP73 1412 BSSP74 70 1 2-14 3 2-14 10 10 5 8 1412 BSSP103 1412 BSSP104 125 1 2/0-14 3 2/0-14 12 12 5 11 1412 BSSP203 1412 BSSP204 225 1 300MCM-6 3 2/0-14 18 12 6 16 1412 BSSP403 1412 BSSP404 400 1 600MCM-2 3 600MCM-2 22 20 8 34 1412 BSSP603 1412 BSSP604 600 2 600MCM-2 2 600MCM-2 26 25 8 49MAIN LUGS BRANCH LUGSMAX AMP. CU-ALSHIP WGHT LBS.CATALOG NUMBER DIMENSIONS3 WIRES 4 WIRESMAIN LUGS BRANCH LUGSQTY WIRESQTY WIRES QTY WIRES A B C1412 TSSP273 1412 TSSP274 70 1 2-14 6 2-14 24 6 5 12 1412 TSSP373 1412 TSSP374 70 1 2-14 6 2-14 36 6 5 15 1412 TSSP473 1412 TSSP474 70 1 2-14 6 2-14 48 6 5 20 1412 TSSP2103 1412 TSSP2104 125 1 1/0-14 6 2-14 24 6 5 12 1412 TSSP3103 1412 TSSP3104 125 1 1/0-14 6 2-14 36 6 5 15 1412 TSSP4103 1412 TSSP4104 125 1 1/0-14 6 2-14 48 6 5 20 1412 TSSP5103 1412 TSSP5104 125 1 1/0-14 6 2-14 60 6 5 24 1412 TSSP6103 1412 TSSP6104 125 1 1/0-14 6 2-14 72 6 5 28 1412 TSSP2203 ---------- 225 1 300MCM-6 6 2/0-14 24 8 6 19 1412 TSSP3203 1412 TSSP3204 225 1 300MCM-6 6 2/0-14 36 8 6 26 1412 TSSP4203 1412 TSSP4204 225 1 300MCM-6 6 2/0-14 48 8 6 32 1412 TSSP5203 1412 TSSP5204 225 1 300MCM-6 6 2/0-14 60 8 6 40 1412 TSSP6203 1412 TSSP6204 225 1 300MCM-6 6 2/0-14 72 8 6 46 1412 TSSP3403 ---------- 400 2 250MCM-1/0* 6 4/0-14 36 11 8 34 1412 TSSP4403 1412 TSSP4404 400 2 250MCM-1/0* 6 4/0-14 48 11 8 42 1412 TSSP5403 1412 TSSP5404 400 2 250MCM-1/0* 6 4/0-14 60 11 8 50 1412 TSSP6403 1412 TSSP6404 400 2 250MCM-1/0* 6 4/0-14 72 11 8 59 1412 TSSP4603 1412 TSSP4604 600 4 250MCM-1/0%u2020 6 4/0-14 48 11 8 42 1412 TSSP5603 1412 TSSP5604 600 4 250MCM-1/0%u2020 6 4/0-14 60 11 8 50 1412 TSSP6603 1412 TSSP6604 600 4 250MCM-1/0%u2020 6 4/0-14 72 11 8 59 * OR 1 x 600MCM-2 %u2020 OR 2 x 600MCM-2 For 4 wire systems, add 1 lb to weight.
