215DATA SUBJECT TO CHANGE WITHOUT NOTICE.1100 BT ELECTRICAL DISTRIBUTIONNote : EXM lugs must be ordered separately. See pages 218-222 for different types of lugs.BUS BAR SPLITTER TROUGHS WITH ALUMINIUM BUS BARSCATALOG # A B CCU NOM. AMP D E3 WIRES 4 WIRES 5 WIRESCATALOG # A B C CATALOG # A B C 600 1100 BT08603 96 24 8 1100 BT08604 96 30 8 1100 BT08605 96 36 8 72 16.75 600 1100 BT09603 108 24 8 1100 BT09604 108 30 8 1100 BT09605 108 36 8 81 16.75 600 1100 BT10603 120 24 8 1100 BT10604 120 30 8 1100 BT10605 120 36 8 90 16.75 600 1100 BT11603 132 24 8 1100 BT11604 132 30 8 1100 BT11605 132 36 8 99 16.75 600 1100 BT12603 144 24 8 1100 BT12604 144 30 8 1100 BT12605 144 36 8 108 16.75 800 1100 BT03803 36 24 8 1100 BT03804 36 30 8 1100 BT03805 36 36 8 27 7.75 800 1100 BT04803 48 24 8 1100 BT04804 48 30 8 1100 BT04805 48 36 8 36 7.75 800 1100 BT05803 60 24 8 1100 BT05804 60 30 8 1100 BT05805 60 36 8 45 13.75 800 1100 BT06803 72 24 8 1100 BT06804 72 30 8 1100 BT06805 72 36 8 54 16.75 800 1100 BT07803 84 24 8 1100 BT07804 84 30 8 1100 BT07805 84 36 8 63 16.75 800 1100 BT08803 96 24 8 1100 BT08804 96 30 8 1100 BT08805 96 36 8 72 16.75 800 1100 BT09803 108 24 8 1100 BT09804 108 30 8 1100 BT09805 108 36 8 81 16.75 800 1100 BT10803 120 24 8 1100 BT10804 120 30 8 1100 BT10805 120 36 8 90 16.75 800 1100 BT11803 132 24 8 1100 BT11804 132 30 8 1100 BT11805 132 36 8 99 16.75 800 1100 BT12803 144 24 8 1100 BT12804 144 30 8 1100 BT12805 144 36 8 108 16.75 1000 1100 BT051003 60 24 8 1100 BT051004 60 30 8 1100 BT051005 60 36 8 45 13.75 1000 1100 BT061003 72 24 8 1100 BT061004 72 30 8 1100 BT061005 72 36 8 54 16.75 1000 1100 BT071003 84 24 8 1100 BT071004 84 30 8 1100 BT071005 84 36 8 63 16.75 1000 1100 BT081003 96 24 8 1100 BT081004 96 30 8 1100 BT081005 96 36 8 72 16.75 1000 1100 BT091003 108 24 8 1100 BT091004 108 30 8 1100 BT091005 108 36 8 81 16.75 1000 1100 BT101003 120 24 8 1100 BT101004 120 30 8 1100 BT101005 120 36 8 90 16.75 1000 1100 BT111003 132 24 8 1100 BT111004 132 30 8 1100 BT111005 132 36 8 99 16.75 1000 1100 BT121003 144 24 8 1100 BT121004 144 30 8 1100 BT121005 144 36 8 108 16.75 1200 1100 BT051203 60 24 8 1100 BT051204 60 30 8 1100 BT051205 60 36 8 45 13.75 1200 1100 BT061203 72 24 8 1100 BT061204 72 30 8 1100 BT061205 72 36 8 54 16.75 1200 1100 BT071203 84 24 8 1100 BT071204 84 30 8 1100 BT071205 84 36 8 63 16.75 1200 1100 BT081203 96 24 8 1100 BT081204 96 30 8 1100 BT081205 96 36 8 72 16.75 1200 1100 BT091203 108 24 8 1100 BT091204 108 30 8 1100 BT091205 108 36 8 81 16.75 1200 1100 BT101203 120 24 8 1100 BT101204 120 30 8 1100 BT101205 120 36 8 90 16.75 1200 1100 BT111203 132 24 8 1100 BT111204 132 30 8 1100 BT111205 132 36 8 99 16.75 1200 1100 BT121203 144 24 8 1100 BT121204 144 30 8 1100 BT121205 144 36 8 108 16.75 1600 1100 BT051603 60 27 8 1100 BT051604 60 32 10 1100 BT051605 60 37 10 45 13.75 1600 1100 BT061603 72 27 8 1100 BT061604 72 32 10 1100 BT061605 72 37 10 54 16.75 1600 1100 BT071603 84 27 8 1100 BT071604 84 32 10 1100 BT071605 84 37 10 63 16.75 1600 1100 BT081603 96 27 8 1100 BT081604 96 32 10 1100 BT081605 96 37 10 72 16.75 1600 1100 BT091603 108 27 8 1100 BT091604 108 32 10 1100 BT091605 108 37 10 81 16.75 1600 1100 BT101603 120 27 8 1100 BT101604 120 32 10 1100 BT101605 120 37 10 90 16.75 1600 1100 BT111603 132 27 8 1100 BT111604 132 32 10 1100 BT111605 132 37 10 99 16.75 1600 1100 BT121603 144 27 8 1100 BT121604 144 32 10 1100 BT121605 144 37 10 108 16.75 2000 1100 BT062003 72 30 9 1100 BT062004 72 37 10 1100 BT062005 72 44 10 54 16.75 2000 1100 BT072003 84 30 9 1100 BT072004 84 37 10 1100 BT072005 84 44 10 63 16.75 2000 1100 BT082003 96 30 9 1100 BT082004 96 37 10 1100 BT082005 96 44 10 72 16.75 2000 1100 BT092003 108 30 9 1100 BT092004 108 37 10 1100 BT092005 108 44 10 81 16.75 2000 1100 BT102003 120 30 9 1100 BT102004 120 37 10 1100 BT102005 120 44 10 90 16.75 2000 1100 BT112003 132 30 9 1100 BT112004 132 37 10 1100 BT112005 132 44 10 99 16.75 2000 1100 BT122003 144 30 9 1100 BT122004 144 37 10 1100 BT122005 144 44 10 108 16.75 2500 1100 BT062503 72 30 9 1100 BT062504 72 37 10 1100 BT062505 72 44 10 54 16.75 2500 1100 BT072503 84 30 9 1100 BT072504 84 37 10 1100 BT072505 84 44 10 63 16.75 2500 1100 BT082503 96 30 9 1100 BT082504 96 37 10 1100 BT082505 96 44 10 72 16.75 2500 1100 BT092503 108 30 9 1100 BT092504 108 37 10 1100 BT092505 108 44 10 81 16.75 2500 1100 BT102503 120 30 9 1100 BT102504 120 37 10 1100 BT102505 120 44 10 90 16.75 2500 1100 BT112503 132 30 9 1100 BT112504 132 37 10 1100 BT112505 132 44 10 99 16.75 2500 1100 BT122503 144 30 9 1100 BT122504 144 37 10 1100 BT122505 144 44 10 108 16.75 Bus bar also available drilled and tapped 1/4 - 20 at 6%u201d interval, add suffix %u2018DT%u2019 to the catalog number (ie. 1100 BT...DT)
