Page 276 - Demo

exmweb.com | 1-800-363-2423 | [email protected] 3 ENCLOSURESSMALL SINGLE DOOR WEATHERPROOF ENCLOSURES2445300 ESCHThe 5300 ESCH single door weatherproof enclosures are used as junction boxes or control boxes in outdoor or indoor installations to protect equipment against rain, sleet and snow. CSA Certified / UL Listed / NEMA / EEMAC 3 / IP64 Technical specifications:%u2022 Made of high quality steel with continuously welded corner seams. %u2022 Opening has a flat lip around all sides to increase rigidity and prevent dripping water from entering the enclosure when the door is open. %u2022 Seamless gasket ensures a complete and durable water tight seal. %u2022 The enclosure has die cast hinges, with stainless steel pins. %u2022 Covers are interchangeable and can be removed by unfastening the antivibration lock nuts. %u2022 Padlockable draw pull catches. %u2022 Enclosure comes complete with a galvanized inner panel. %u2022 External wall mounting feet are provided. %u2022 Finished with heat fused powder paint, electrostatically applied on a pretreated base. %u2022 Paint color : ANSI/ASA 61 smooth gray. %u2022%u201d%u201d%u201d%u201dCATALOG NUMBER A B C D E FDIMENSIONS SHIP WGHT LBS.5300 ESCH060604 6 6 4 4.88 4.88 7.125 5 5300 ESCH080604 8 6 4 6.88 4.88 9.125 6 5300 ESCH080806 8 8 6 6.88 6.88 9.125 8 5300 ESCH100806 10 8 6 8.88 6.88 11.125 10 5300 ESCH121006 12 10 6 10.88 8.88 13.125 12 5300 ESCH121207 12 12 7 10.88 10.88 13.125 15p.596
