NEMA 1 ENCLOSURES1941100 EHTYPE EH JUNCTION BOXES3.375%u201dW X Y Z3.375%u201d 3.375%u201d KNOCKOUT PATTERNCONDUIT SIZES1/2-3/4 1/2-3/4 1/2-3/4 1/2-3/4The 1100 EH are used as surface mounting welded hinge junction boxes, switch boxes or general service boxes. CSA Certified / UL Listed / NEMA / EEMAC 1 / IP30 Technical specifications:%u2022 Made of high quality steel. %u2022 These boxes have knockouts. %u2022 Enclosures are closed with %u00bc turn locks. %u2022 The hinge system is enhanced with welded hinges and crimped hinge pin %u2022 Four internal mounting holes, and a bonding screw are provided. %u2022 Finished with heat fused powder paint, electrostatically applied on a pretreated base. %u2022 Paint color : ANSI/ASA 61 smooth gray. %u201dBRACKET HINGES %u201d1.688%u201d 1.688%u201d 1.688%u201dKNOCKOUT PATTERNCONDUIT SIZES1/2-3/4 1/2-3/4 1/2-3/4 1/2-3/41.875%u201d 1.875%u201d 1.688%u201d 1.688%u201d 1.688%u201d3/4-1 3/4-1 1 /4 -1 1 3/4-1 3/4-11 2 3 4 5 6 7 8 9p.540 p.506 p.510 p.507 p.592 p.617exmweb.com | 1-800-363-2423 | [email protected]
