exmweb.com | 1-800-363-2423 | [email protected] 12-13 MTRX RAILS & CABLE CLAMPS102The 886 GPCE cable entry gland plate is installed mainly on the bottom cover of a standard Mtrx cabinet. The steel plate is supplied in individual packs with three 3 inch plastic blanking caps. Supplied with gland plate depth of 200mm only (short side). Standard finish RAL7011 textured dark gray. The 886 GPG kit is comprised of a Polyurethane foam gasket used to offer additional protection where cables enter the enclosure via the supplied gland plates. Kit consists of all hardware required for sealing one gland plate seam. CATALOG NUMBER886 GPG04 400 886 GPG06 600 & 1200 886 GPG07 700 886 GPG08 800 & 1600 886 GPG09 900 886 GPG10 1000FITS ON GLAND PLATES FOR WIDTH (MM) The 886 CT kit is comprised of a pair of 16 GA or 14 GA sheet metal guides. Guides are installed directly onto the cabinet frame in any direction (height, width or depth). The cable guides are supplied with features enabling the use of tie wraps throughout the entire length of the parts. Finish is textured dark gray RAL7011. Supplied with all necessary mounting hardware. CATALOG NUMBERFIT ON TROUGH DEPTH FITS IN CABINET WIDTH 886 GPCE0602 886 GPCE0702 886 GPCE0802 886 GPCE0902 886 GPCE1002600 & 1200 700 800 & 1600 900 1000400 TO 1200 400 TO 1200 400 TO 1200 400 TO 1200 400 TO 1200NOTE: Only the 886 GPCE0602 can be installed on cable entry top covers 6500 MXTC (p.54) NOTE: Gland plate not provided, kit is intended for retrofitting onto gland plates supplied with cabinet bottom cover886 CT04 886 CT05 886 CT06 886 CT07 886 CT08 886 CT09 886 CT10 886 CT12 886 CT14 886 CT16 886 CT18 886 CT20 886 CT22295 395 495 595 695 795 895 1095 1295 1495 1695 1895 2095400 500 600 700 800 900 1000 1200 1400 1600 1800 2000 2200CATALOG NUMBERLENGTH (MM)FITS IN NOMINAL CABINET /FRAME DIMENSION (MM) CABLE ENTRY GLAND PLATECABLE ENTRY PROTECTIVE FOAM FOR GLAND PLATECABLE GUIDE
