exmweb.com | 1-800-363-2423 | [email protected] 12-13 MTRX RAILS & CABLE CLAMPS100The 6500 MXTSB transformer support brackets are used to mount transformers and other heavy equipment at the bottom of the cabinet. The kit includes two support brackets and installation hardware.CATALOG NUMBER6500 MXTSB04 400mm 6500 MXTSB06 600mm 6500 MXTSB07 700mm 6500 MXTSB08 800mm 6500 MXTSB09 900mm 6500 MXTSB10 1000mm 6500 MXTSB12 1200mm 6500 MXTSB16 1600mm FITS CABINET WIDTHThe 6500 MXCRAIL cable collecting rail kit is used to fasten cable clamps in order to provide strain relief prior to making connections to equipment. The collecting rail kit includes one rail, two fastening brackets and all installation hardware. The rail can be rotated by increments of 45%u00b0 to assist in cable routing. CATALOG NUMBERFITS CABINET WIDTH6500 MXCRAIL 6500 MXTSB 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 22006500 MXCRAIL03 6500 MXCRAIL04 6500 MXCRAIL05 6500 MXCRAIL06 6500 MXCRAIL07 6500 MXCRAIL08 6500 MXCRAIL09 6500 MXCRAIL10 6500 MXCRAIL11 6500 MXCRAIL12 6500 MXCRAIL13 6500 MXCRAIL14 6500 MXCRAIL15 6500 MXCRAIL16 6500 MXCRAIL17 6500 MXCRAIL18 6500 MXCRAIL19 6500 MXCRAIL20 6500 MXCRAIL21 6500 MXCRAIL22 NOTE*: standard c-rails have 5/8 inch opening. For smaller opening rail (16 mm) add suffix %u2018S%u2019. The smaller rails will accomodate the 886UB cable clamps. (p.101)*The 6500 MXTSA transformer support bracket allow the installation of heavy equipment at different height inside Mtrx modular cabinets.The kit includes four support angles and installation hardware. Note: The transformer support angles are designed to be used with the 6500 MXTSB. CATALOG NUMBER6500 MXTSA Transformer support bracket DESCRIPTIONTRANSFORMER SUPPORT ANGLESTRANSFORMER SUPPORT BRACKETC TYPE CABLE COLLECTING RAILS
