exmweb.com | 1-800-363-2423 | [email protected] 12-13 MTRX RAILS & CABLE CLAMPSGRID RAIL SYSTEM98The 6500 MXG grid rail system is used to expand the mounting capabilities of Mtrx cabinets. Grid rails can be installed horizontally or vertically, anywhere within the cabinet frame, using separately ordered installation brackets. Two types of brackets are available. To mount grid rails to the cabinet frame, order the 6500 MXGF brackets. To mount grid rails to other rails, order the 6500 MXGG brackets. Quick fix rails, which do not require installation brackets, are also available. The 6500 MXGQ quick fix rails can only be installed on the cabinet sides, along the cabinet%u2019s depth. Instruments can be installed on the rails using the self-tapping screws, cage nuts or sliding nuts, which can be ordered separately. Quick Fix Rail (No brackets) 6500 MXGQStandard Rail+ Frame brackets 6500 MXG+ 6500 MXGF1Sliding M6 or M8 nuts installed to slide within grid rail either on open or cutout side. 886 HDGSStandard Rail+ Grid brackets 6500 MXG+ 6500 MXGG3
