p.125 p.125 p.124 p.125 p.70 p.70 p.70 p.49 p.70Lifting Angles6500 MXSCE010404 6500 MXSCE010405 6500 MXSCE010406 6500 MXSCE010408 6500 MXSCE010604 6500 MXSCE010605 6500 MXSCE010606 6500 MXSCE010608 6500 MXSCE010609 6500 MXSCE010610 6500 MXSCE010612 6500 MXSCE010704 6500 MXSCE010705 6500 MXSCE010706 6500 MXSCE010708 6500 MXSCE010709 6500 MXSCE010710 6500 MXSCE010712 6500 MXSCE010804 6500 MXSCE010805 6500 MXSCE010806 6500 MXSCE010808400 400 400 500 400 600 400 800 600 400 600 500 600 600 600 800 600 900 600 1000 600 1200 700 400 700 500 700 600 700 800 700 900 700 1000 700 1200 800 400 800 500 800 600 800 800 69NEMA 12-13 MTRX CABINETSDATA SUBJECT TO CHANGE WITHOUT NOTICE.W DC (HEIGHT)SEE NOTEBELOW25.0mm49mm45.0mmOPENINGCLEARANCEONBOTH SIDESORIENTATION SHOWN ISFOR TOP INSTALLATION.ROTATE 180%u00b0 FOR BOTTOMINSTALLATIONCATALOG NUMBER W DNOMINALW DCATALOG NOMINALNUMBER6500 MXSCE010809 6500 MXSCE010810 6500 MXSCE010812 6500 MXSCE010904 6500 MXSCE010905 6500 MXSCE010906 6500 MXSCE010908 6500 MXSCE011004 6500 MXSCE011005 6500 MXSCE011006 6500 MXSCE011008 6500 MXSCE011204 6500 MXSCE011205 6500 MXSCE011206 6500 MXSCE011208 6500 MXSCE011604 6500 MXSCE011605 6500 MXSCE011606 6500 MXSCE011608 6500 MXSCE011805 6500 MXSCE011806 800 900 800 1000 800 1200 900 400 900 500 900 600 900 800 1000 400 1000 500 1000 600 1000 800 1200 400 1200 500 1200 600 1200 800 1600 400 1600 500 1600 600 1600 800 1800 500 1800 600 The 6500 MXSCE solid top or bottom cable entry trough is installed on the top or base of a Mtrx cabinet. It is made of steel or stainless steel. This variable height symmetric trough was developed for applications where cables, bus bars or pipes are to be run into the enclosure via the top or bottom without having to order either a separate top or bottom cover. The troughs are an extension of the controlled volume of the enclosure, retaining the NEMA 12 rating. Supplied standard with: (i) all installation hardware; (ii) sealing plugs in eye bolt or leveling feet mounting holes. Standard finish is powder coated RAL7011 Sandtex dark gray Note: End plates are sold separately. Refer to page 70 Default HEIGHT %u2018C%u2019 is 100mm, for 200mm, 300mm, 400mm height replace %u201901%u2019 in part number by %u201902%u2019, %u201903%u2019, %u201904%u2019 respectively. Default installation is on top, for bottom installation add suffix %u2018B%u2019 i.e.: 6500 MXSCE010806 %uf0b0 100mm high installed on top 6500 MXSCE030806B %uf0b0 300mm high installed on bottom 6500 MXSCESOLID TOP OR BOTTOM CABLE ENTRY TROUGH
