SECTION A-AAAABCDF4.875EYEBOLTSEFULL PANEL (OPTIONAL) HALF PANEL (OPTIONAL).875q1/4 TURN LOCK1.6191.719 7.619p.615 p.616 p.624 p.646 p.642 p.540 p.592DATA SUBJECT TO CHANGE WITHOUT NOTICE.The 9412 SSDD water, oil & dust tight enclosures are used indoors or outdoors in areas where the enclosures may be subject to hosing or water coming from any direction, or for protection against dust, dirt or oil splashing. CSA Certified / UL Listed NEMA/EEMAC 4X / IP66 Technical specifications: %u2022 Made of high quality codegauge (type 304) stainlesssteel, with continuously welded corner seams.%u2022 Curled lip around all sides toincrease rigidity and preventdripping water from enteringthe enclosure when the dooris open.%u2022 Seamless gasket ensures acomplete and durable watertight seal.%u2022 Concealed hinges can bepulled out to remove thedoor.%u2022 Quarter turn locking mechanisms on three sides of the door ensure positive closing. %u2022 Optional inner panels can bemounted at any depth, usingthe three sets of rails weldedon the sides of the cabinet.%u2022 Side panels can also beordered separately.%u2022 A print pocket is provided.%u2022 The enclosures are brushedsmooth.%u2022 Finished with heat fused powder paint, electrostaticallyapplied on a pretreatedbase.%u2022 Paint color : ANSI/ASA 61smooth gray.Insulated box? To have your enclosure insulated, add suffix %u201cTH%u201di.e.: 9412 SSDD724818TH %uf0b0 Insulated steel enclosureCATALOG NUMBER A B C D E FDIMENSIONS SHIP WGHT LBS. FULL HALFEQUIPMENT PANEL889 FP6048 889 HP6048 464 889 FP7248 889 HP7248 625 889 FP7260 889 HP7260 639 889 FP7272 889 HP7272 689 889 FP7248 889 HP7248 702 889 FP7260 889 HP7260 760 889 FP7272 889 HP7272 772 889 FP7260 889 HP7260 766 889 FP9048 889 HP9048 842 889 FP9072 889 HP9072 870 889 FP9072 889 HP9072 882 889 FP9072 889 HP9072 8989412 SSDD604818 9412 SSDD724818 9412 SSDD726018 9412 SSDD727218 9412 SSDD724824 9412 SSDD726024 9412 SSDD727224 9412 SSDD726036 9412 SSDD904820 9412 SSDD907220 9412 SSDD907224 9412 SSDD90723660 72 72 72 72 72 72 72 90 90 90 9048 48 60 72 48 60 72 60 48 72 72 7218 18 18 18 24 24 24 36 20 20 24 3648 60 60 60 60 60 60 60 78 78 78 7844 44 56 68 44 56 68 56 44 68 68 6824.875 30.875 30.875 30.875 30.875 30.875 30.875 30.875 39.875 39.875 39.875 39.875STAINLESS STEEL FREE STANDING DOUBLE DOOR ENCLOSURES9412 SSDD NEMA 4X ENCLOSURES393
