OMIT IFA=30 po OR LESSOMIT IFB=30 po OR LESSREMOVABLECENTER POSTPOWDER COATED12 GA STEELPOUREDGASKETMETAL %u00bcLOCK- %u201d- %u201d%u201d%u201d%u201d%u201d%u201d%u201d%u201dThe 5412 ESDDHD water, oil & dust tight enclosures are used indoors or outdoors, in areas where a corrosion problem exists or where the enclosures may be subject to hosing or water coming from any direction, or for protection against dust, dirt or oil splashing. CSA Certified / UL Listed NEMA/EEMAC 4-12/ IP66 Technical specifications: %u2022 Made of high quality 12 GA steam with continuously welded corner seams. %u2022 The opening has a curled lip around all sides to increase rigidity and prevent dripping water from entering the enclosure when the cover has been removed. %u2022 A high quality, robotically poured-in-place, seamless gasket ensures a complete and durable water tight seal. %u2022 Quarter turn locking mechanisms on all sides ensure positive closing. %u2022 Internal mounting holes are provided. %u2022 Each enclosure comes complete with a 12 GA galvanized inner panel, which is double bent* for maximum rigidity and mounts on M8 welded studs. %u2022 The enclosures are brushed smooth. %u2022 Inner panel is galvanized (other colors available).323DATA SUBJECT TO CHANGE WITHOUT NOTICE.Optional mounting feet5412 ESDDHD NEMA 4-12 ENCLOSURESDOUBLE DOOR QUARTER TURN COVER ENCLOSURESCATALOG NUMBER A B C D E F GDIMENSIONS SHIP WGHT LBS.Insulated box? To have your enclosure insulated, add suffix %u201cTH%u201di.e.: 5412 ESDDHD244208TH %uf0b0 Insulated steel enclosure5412 ESDDHD244208 24 42 8 22 40 25.25 36 117 5412 ESDDHD244808 24 48 8 22 46 25.25 42 130 5412 ESDDHD544208 54 42 8 52 40 55.25 36 272 5412 ESDDHD244210 24 42 10 22 40 25.25 36 150 5412 ESDDHD304210 30 42 10 28 40 31.25 36 152 5412 ESDDHD304810 30 48 10 28 46 31.25 42 168 5412 ESDDHD306010 30 60 10 28 58 31.25 54 203 5412 ESDDHD364212 36 42 12 34 40 37.25 36 220 5412 ESDDHD364812 36 48 12 34 46 37.25 42 242 5412 ESDDHD366012 36 60 12 34 58 37.25 54 292 5412 ESDDHD424212 42 42 12 40 40 43.25 36 197 5412 ESDDHD424812 42 48 12 40 46 43.25 42 216 5412 ESDDHD426012 42 60 12 40 58 43.25 54 349 5412 ESDDHD484812 48 48 12 46 46 49.25 42 225%u2020 For stainless steel type 316, add suffix %u20186%u2019 to the catalog number (ie. 5412 ESDDHD2442086). %u2021 For painted stainless steel, add suffix %u2018P%u2019 to the catalog number (ie. 5412 ESDDHD544208P).
