87NEMA 12-13 MTRX MULTI-DOOR SOLUTIONSDATA SUBJECT TO CHANGE WITHOUT NOTICE.The 6500 MXJO5 light duty joining brackets are used to join Mtrx modular cabinets once they are being joined at their final on site location. Note: These joining brackets are not to be used where lineups are to be transported in one piece. CATALOG NUMBER6500 MXJO5 Light duty joining brackets The 6500 MXJO6 external rapid joining brackets are an alternative in joining cabinets from the outside with minimal rework or from the inside with no added hardware. Note: These joining brackets are not to be used where lineups are to be transported in one piece. CATALOG NUMBER6500 MXJO6 External / Internal rapid joining bracketsDESCRIPTIONThe 6500 MXJO4 joining gasket kit is used in conjunction with a joining bracket kit (see p.86) to maintain the cabinets environmental integrity. One size fits all.CATALOG NUMBER6500 MXJO4 Joining gasket DESCRIPTIONDESCRIPTIONThe 6500 MXMJXX joining panel is installed between two adjacent mounting panels (6500 MXM) in order to provide one continuous and removable mounting surface within the full height and width of the line-up. Note: Adjacent inner panels are required to be installed 25mm forward to accommodate. CATALOG NUMBER6500 MXMJ07 700 6500 MXMJ14 1400 6500 MXMJ16 1600 6500 MXMJ18 1800 6500 MXMJ20 2000 6500 MXMJ22 2200 FITS CABINET HEIGHT (MM) Add suffix %u2018W%u2019 For panel painted white RAL9003 LIGHT DUTY JOINING BRACKETSEXTERNAL JOINING BRACKETSJOINING GASKETJOINING PANEL
