225DATA SUBJECT TO CHANGE WITHOUT NOTICE.1412 BTSSCU ELECTRICAL DISTRIBUTIONNote : EXM lugs must be ordered separately. See pages 218-222 for different types of lugs.WATERTIGHT BUS BAR SPLITTER TROUGHS WITH COPPER BUS BARSCATALOG # A B CCU NOM. AMP D E3 WIRES 4 WIRES 5 WIRESCATALOG # A B C CATALOG # A B C600 1412 BTSSCU03603 36 24 10 1412 BTSSCU03604 36 30 10 1412 BTSSCU03605 36 36 10 27 7.75 600 1412 BTSSCU04603 48 24 10 1412 BTSSCU04604 48 30 10 1412 BTSSCU04605 48 36 10 36 7.75 600 1412 BTSSCU05603 60 24 10 1412 BTSSCU05604 60 30 10 1412 BTSSCU08605 60 36 10 72 13.75 600 1412 BTSSCU05603 72 24 10 1412 BTSSCU06604 72 30 10 1412 BTSSCU06605 72 36 10 54 16.75 600 1412 BTSSCU07603 84 24 10 1412 BTSSCU07604 84 30 10 1412 BTSSCU07605 84 36 10 63 16.75 600 1412 BTSSCU08603 96 24 10 1412 BTSSCU08604 96 30 10 1412 BTSSCU08605 96 36 10 72 16.75 600 1412 BTSSCU09603 108 24 10 1412 BTSSCU09604 108 30 10 1412 BTSSCU09605 108 36 10 81 16.75 600 1412 BTSSCU10603 120 24 10 1412 BTSSCU10604 120 30 10 1412 BTSSCU10605 120 36 10 90 16.75 600 1412 BTSSCU11603 132 24 10 1412 BTSSCU11604 132 30 10 1412 BTSSCU11605 132 36 10 99 16.75 600 1412 BTSSCU12603 144 24 10 1412 BTSSCU12604 144 30 10 1412 BTSSCU12605 144 36 10 108 16.75 800 1412 BTSSCU03803 36 24 10 1412 BTSSCU03804 36 30 10 1412 BTSSCU03805 36 36 10 27 7.75 800 1412 BTSSCU04803 48 24 10 1412 BTSSCU04804 48 30 10 1412 BTSSCU04805 48 36 10 36 7.75 800 1412 BTSSCU05803 60 24 10 1412 BTSSCU05804 60 30 10 1412 BTSSCU05805 60 36 10 45 13.75 800 1412 BTSSCU06803 72 24 10 1412 BTSSCU06804 72 30 10 1412 BTSSCU06805 72 36 10 54 16.75 800 1412 BTSSCU07803 84 24 10 1412 BTSSCU07804 84 30 10 1412 BTSSCU07805 84 36 10 63 16.75 800 1412 BTSSCU08803 96 24 10 1412 BTSSCU08804 96 30 10 1412 BTSSCU08805 96 36 10 72 16.75 800 1412 BTSSCU09803 108 24 10 1412 BTSSCU09804 108 30 10 1412 BTSSCU09805 108 36 10 81 16.75 800 1412 BTSSCU10803 120 24 10 1412 BTSSCU10804 120 30 10 1412 BTSSCU10805 120 36 10 90 16.75 800 1412 BTSSCU11803 132 24 10 1412 BTSSCU11804 132 30 10 1412 BTSSCU11805 132 36 10 99 16.75 800 1412 BTSSCU12803 144 24 10 1412 BTSSCU12804 144 30 10 1412 BTSSCU12805 144 36 10 108 16.75 1000 1412 BTSSCU051003 60 24 10 1412 BTSSCU051004 60 30 10 1412 BTSSCU051005 60 36 10 45 13.75 1000 1412 BTSSCU061003 72 24 10 1412 BTSSCU061004 72 30 10 1412 BTSSCU061005 72 36 10 54 16.75 1000 1412 BTSSCU071003 84 24 10 1412 BTSSCU071004 84 30 10 1412 BTSSCU071005 84 36 10 63 16.75 1000 1412 BTSSCU081003 96 24 10 1412 BTSSCU081004 96 30 10 1412 BTSSCU081005 96 36 10 72 16.75 1000 1412 BTSSCU091003108 24 10 1412 BTSSCU091004108 30 10 1412 BTSSCU091005108 36 10 81 16.75 1000 1412 BTSSCU101003120 24 10 1412 BTSSCU101004120 30 10 1412 BTSSCU101005120 36 10 90 16.75 1000 1412 BTSSCU111003132 24 10 1412 BTSSCU111004132 30 10 1412 BTSSCU111005132 36 10 99 16.75 1000 1412 BTSSCU121003144 24 10 1412 BTSSCU121004144 30 10 1412 BTSSCU121005144 36 10 108 16.75 1200 1412 BTSSCU051203 60 24 10 1412 BTSSCU051204 60 30 10 1412 BTSSCU051205 60 36 10 45 13.75 1200 1412 BTSSCU061203 72 24 10 1412 BTSSCU061204 72 30 10 1412 BTSSCU061205 72 36 10 54 16.75 1200 1412 BTSSCU071203 84 24 10 1412 BTSSCU071204 84 30 10 1412 BTSSCU071205 84 36 10 63 16.75 1200 1412 BTSSCU081203 96 24 10 1412 BTSSCU081204 96 30 10 1412 BTSSCU081205 96 36 10 72 16.75 1200 1412 BTSSCU091203108 24 10 1412 BTSSCU091204108 30 10 1412 BTSSCU091205108 36 10 81 16.75 1200 1412 BTSSCU101203120 24 10 1412 BTSSCU101204120 30 10 1412 BTSSCU101205120 36 10 90 16.75 1200 1412 BTSSCU111203132 24 10 1412 BTSSCU111204132 30 10 1412 BTSSCU111205132 36 10 99 16.75 1200 1412 BTSSCU121203144 24 10 1412 BTSSCU121204144 30 10 1412 BTSSCU121205144 36 10 108 16.75 1600 1412 BTSSCU051603 60 27 10 1412 BTSSCU051604 60 32 12 1412 BTSSCU051605 60 37 12 45 13.75 1600 1412 BTSSCU061603 72 27 10 1412 BTSSCU061604 72 32 12 1412 BTSSCU061605 72 37 12 54 16.75 1600 1412 BTSSCU071603 84 27 10 1412 BTSSCU071604 84 32 12 1412 BTSSCU071605 84 37 12 63 16.75 1600 1412 BTSSCU081603 96 27 10 1412 BTSSCU081604 96 32 12 1412 BTSSCU081605 96 37 12 72 16.75 1600 1412 BTSSCU091603108 27 10 1412 BTSSCU091604108 32 12 1412 BTSSCU091605108 37 12 81 16.75 1600 1412 BTSSCU101603120 27 10 1412 BTSSCU101604120 32 12 1412 BTSSCU101605120 37 12 90 16.75 1600 1412 BTSSCU111603132 27 10 1412 BTSSCU111604132 32 12 1412 BTSSCU111605132 37 12 99 16.75 1600 1412 BTSSCU121603144 27 10 1412 BTSSCU121604144 32 12 1412 BTSSCU121605144 37 12 108 16.75 2000 1412 BTSSCU062003 72 30 10 1412 BTSSCU062004 72 37 12 1412 BTSSCU062005 72 44 12 54 16.75 2000 1412 BTSSCU072003 84 30 10 1412 BTSSCU072004 84 37 12 1412 BTSSCU072005 84 44 12 63 16.75 2000 1412 BTSSCU082003 96 30 10 1412 BTSSCU082004 96 37 12 1412 BTSSCU082005 96 44 12 72 16.75 2000 1412 BTSSCU092003108 30 10 1412 BTSSCU092004108 37 12 1412 BTSSCU092005108 44 12 81 16.75 2000 1412 BTSSCU102003120 30 10 1412 BTSSCU102004120 37 12 1412 BTSSCU102005120 44 12 90 16.75 2000 1412 BTSSCU112003132 30 10 1412 BTSSCU112004132 37 12 1412 BTSSCU112005132 44 12 99 16.75 2000 1412 BTSSCU122003144 30 10 1412 BTSSCU122004144 37 12 1412 BTSSCU122005144 44 12 108 16.75 2500 1412 BTSSCU062503 72 30 10 1412 BTSSCU062504 72 37 12 1412 BTSSCU062505 72 44 12 54 16.75 2500 1412 BTSSCU072503 84 30 10 1412 BTSSCU072504 84 37 12 1412 BTSSCU072505 84 44 12 63 16.75 2500 1412 BTSSCU082503 96 30 10 1412 BTSSCU082504 96 37 12 1412 BTSSCU082505 96 44 12 72 16.75 2500 1412 BTSSCU092503108 30 10 1412 BTSSCU092504108 37 12 1412 BTSSCU092505108 44 12 81 16.75 2500 1412 BTSSCU102503120 30 10 1412 BTSSCU102504120 37 12 1412 BTSSCU102505120 44 12 90 16.75 2500 1412 BTSSCU112503132 30 10 1412 BTSSCU112504132 37 12 1412 BTSSCU112505132 44 12 99 16.75 2500 1412 BTSSCU122503144 30 10 1412 BTSSCU122504144 37 12 1412 BTSSCU122505144 44 12 108 16.75 Bus bar also available drilled and tapped 1/4 - 20 at 6%u201d interval, add suffix %u2018DT%u2019 to the catalog number (ie. 1412 BTSSCU...DT)%u2021 For painted stainless steel, add suffix %u2018P%u2019 to the catalog number (ie. 1412 BTSSCU...P). p.646 p.626 p.693 p.715 p.655 p.227 p.227
