185NEMA 1 ENCLOSURESMEDIUM UTILITY ENCLOSURES1100p.540 p.506 p.592 p.600 p.607 p.628 p.617The 1100 are used where the control installation does not require a high degree of protection (such as watertight or dust tight). CSA Certified / UL Listed / NEMA / EEMAC 1 / IP30 Technical specifications:%u2022 Made of high quality code gauge steel. %u2022 Enclosure comes without inner panel. %u2022 Enclosures are closed with %u00bc turn locks. %u2022 Four internal mounting holes are provided. %u2022 Finished with heat fused powder paint, electrostatically applied on a pretreated base. %u2022 Paint color : ANSI/ASA 61 smooth gray.CATALOG NUMBERSHIP WGHT LBS.1100 161606 16 16 6.870 6 14 14 16 20 1100 162006 16 20 6.870 6 14 18 16 25 1100 201206 20 12 6.870 6 18 10 16 20 1100 201606 20 16 6.870 6 18 14 16 25 1100 202006 20 20 6.870 6 18 18 16 30 1100 241606 24 16 6.870 6 22 14 16 29 1100 242006 24 20 6.870 6 22 18 16 35 1100 242406 24 24 6.870 6 22 22 14 49 1100 302406 30 24 6.870 6 28 22 14 59 1100 362406 36 24 6.870 6 34 22 14 70 1100 363006 36 30 6.870 6 34 28 14 85 1100 161608 16 16 8.870 8 14 14 16 22 1100 201208 20 12 8.870 8 18 10 16 22 1100 201608 20 16 8.870 8 18 14 16 27 1100 202008 20 20 8.870 8 18 18 16 32 1100 242008 24 20 8.870 8 22 18 16 38 1100 242408 24 24 8.870 8 22 22 14 53 1100 302008 30 20 8.870 8 28 18 14 55 1100 302408 30 24 8.870 8 28 22 14 64 1100 303008 30 30 8.870 8 28 28 14 77 1100 362408 36 24 8.870 8 34 22 14 75 1100 363008 36 30 8.870 8 34 28 14 90 1100 202010 20 20 10.870 10 18 18 16 35 1100 242010 24 20 10.870 10 22 18 16 41 1100 302410 30 24 10.870 10 28 22 14 69 1100 242412 24 24 12.870 12 22 22 14 61 1100 302412 30 24 12.870 12 28 22 14 73 1100 363012 36 30 12.870 12 34 28 14 102A B C Ci DBOX & COVER GAUGEEDIMENSIONSDATA SUBJECT TO CHANGE WITHOUT NOTICE.Note : The inner pannel must be ordered separately.
