CATALOG NUMBERCATALOG NUMBER880 GB08 8 10 3 2 880 GB16 16 20 9 3 880 GB24 24 30 15 4SHIP WGHT LBS.A M5 M6.500%u201d.500%u201d 1.000%u201d.500%u201dTYPA.375%u201d 1.625%u201dTHREADED M5SEE TABLE FOR QTY.THREADED M6SEE TABLE FOR QTY.%u00d8 .375%u201dTOP VIEW WITHOUT INSULATORTIN PLATED COPPER BAR.250%u201dINSULATOR8.500%u201d1.000%u201d.563%u201d.500%u201d1.000%u201d 2.250%u201d1.250%u201d.250%u201d2.000%u201d1.000%u201dTHREADED M6WIRE GAUGEGROUNDING ACCESSORIES628Grounding kitsThe 880 GC2 grounding kits are designed for use with both aluminum and copper conductors, of 14 to 2 GA AWG. Lugs are made of a strong and highly conductive alluminum alloy 606-T6 plated over copper, rated at 90%u00b0C. The 880 GC2 are sold in packs of 10.CSA approvedGrounding wiresThe 880 GC1 grounding wires are 8%u00bd%u201d long, made of flexible stranded copper wire and are colored yellow with green stripes. The 880 GC1 have ring-tongue terminals and are used to ensure proper bonding of the door to the cabinet. Installation hardware, consiting of nuts, bolts and washers, is provided. The 880 GC1 are sold in packs of 10.CATALOG NUMBERSHIP WGHT LBS.CATALOG NUMBER880 GC2 1880 GRCB 2Unsulated grounding bars880 GC1 AWG-12 1 880 GC1-A AWG-10 1Grounding barThe 880 GRCB are designed to permit installation of up to 5 grounding wires. Bars are threaded M6. If required, lugs are ordered separately. Kits come complete with installation hardware. The grounding bar is made of copper and is tin plated.exmweb.com | 1-800-363-2423 | [email protected] 880 GB grounding bars come in three sizes, with indoor polyamide resin insulators. The grounding bar is made of copper and is tin plated.
