SIDE PANELSBCAMOUNTING BRACKETFULLPANELHALFPANELPANELCBA889 HSP6018 24 12.500 11 889 HSP6024 24 18.500 20 889 HSP7218 30 12.500 14 889 HSP7224 30 18.500 21 889 HSP7230 30 24.500 22 889 HSP7236 30 30.500 23 889 HSP9020 39 14.500 26 889 HSP9024 39 18.500 28 889 HSP9036 39 30.500 31889 FSP6018 48 12.500 23 889 FSP6024 48 18.500 38 889 FSP7218 60 12.500 27 889 FSP7224 60 18.500 42 889 FSP7230 60 24.500 44 889 FSP7236 60 30.500 47 889 FSP9020 78 14.500 55 889 FSP9024 78 18.500 57 889 FSP9036 78 30.500 60CATALOG NUMBER A BDIMENSIONS SHIP WGHT LBS.CATALOG NUMBER A BDIMENSIONS SHIP WGHT LBS.CATALOG NUMBER A BDIMENSIONS SHIP WGHT LBS.CATALOG NUMBER A BDIMENSIONS SHIP WGHT LBS.889 HP6024 24.875 20 20 889 HP6036 24.875 32 28 889 HP6048 24.875 44 37 889 HP7224 30.875 20 23 889 HP7230 30.875 26 29 889 HP7236 30.875 32 34 889 HP7248 30.875 44 45 889 HP7260 30.875 56 56 889 HP7272 30.875 68 62 889 HP9024 39.875 20 28 889 HP9036 39.875 32 43 889 HP9048 39.875 44 57 889 HP9072 39.875 68 86889 FP6024 48 20 37 889 FP6036 48 32 54 889 FP6048 48 44 72 889 FP7224 60 20 44 889 FP7230 60 26 55 889 FP7236 60 32 66 889 FP7248 60 44 88 889 FP7260 60 56 110889 FP7272 60 68 132 889 FP9024 78 20 55 889 FP9036 78 32 84 889 FP9048 78 44 112 889 FP9072 78 68 169To order inner panels with specific material, add appropriate suffix to the catalog number. *For Galvanized Steel : Add suffix %u2018G%u2019 to the catalog number (ie. 889 FSP9036G). To order inner panels with specific material, add appropriate suffix to the catalog number. *For Galvanized Steel : Add suffix %u2018G%u2019 to the catalog number (ie. 889 FP9072G). Side panels for 9500 freestanding enclosuresBack panels for 9500 freestanding enclosuresThe 889 HSP & 889 FSP side panels are made of 12 GA steel and mount on channels provided in the cabinets. All full sized panels have a lip on height to increase rigidity. Panels are finished with white heat fused powder paint, electrostatically applied on a pretreated base. The 889 FP & HP back panels for the 9500 free standing single and double door enclosures are made of 12 GA steel and mount on brackets provided in the cabinets. All full sized panels have a lip in order to increase rigidity. Panels are finished with white heat fused powder paint, electrostatically applied on a pretreated base. 615DATA SUBJECT TO CHANGE WITHOUT NOTICE.
