BA7.345\1.969\SWING OUT PANELS889 SKWHD6018 24.875 13.3 17 889 SKWHD6024 24.875 19.3 26 889 SKWHD7218 30.875 13.3 22 889 SKWHD7224 30.875 19.3 32 889 SKWHD7230 30.875 25.3 43 889 SKWHD7236 30.875 31.3 54 889 SKWHD9024 39.875 19.3 42 889 SKWHD9036 39.875 31.3 70CATALOG NUMBER A BDIMENSIONS SHIP WGHT LBS.Swing out panels for 9500 and 9412The 889 SKWHD swing out panels are made to be used with freestanding cabinets. Kits can be mounted by piercing small holes on the sides of the enclosures and are mounted with screws. All hardware and mounting instructions are included. Finish is ANSI/ASA 61 gray heat fused powder paint, electrostatically applied on a pretreated base.CATALOG NUMBER889 SKWHD6024 50.5 20.85 52 889 SKWHD6036 50.5 32.85 61 889 SKWHD7224 62.5 20.85 64 889 SKWHD7230 62.5 26.85 70 889 SKWHD7236 62.5 32.85 76 889 SKWHD9024 80.5 20.85 84 889 SKWHD9036 80.5 32.85 140 A BDIMENSIONS SHIP WGHT LBS.614Swing out panels for light duty enclosuresThe 880 SKWLD swing out panels for small enclosures are made to be used with single door enclosures. Kits can be mounted by piercing small holes. All hardware and mounting instructions are included. Finish is ANSI/ASA 61 gray heat fused powder paint, electrostatically applied on a pretreated base. CATALOG NUMBER880 SKWLD1210 10.687 8.5 880 SKWLD1212 10.687 10.5 880 SKWLD1214 10.687 12.5 880 SKWLD1408 12.687 6.5 880 SKWLD1412 12.687 10.5 880 SKWLD1416 12.687 14.5 880 SKWLD1610 14.687 8.5 880 SKWLD1612 14.687 10.5 880 SKWLD1614 14.687 12.5CATALOG NUMBER880 SKWLD0606 4.687 4.5 880 SKWLD0806 6.687 4.5 880 SKWLD0808 6.687 6.5 880 SKWLD0810 6.687 8.5880 SKWLD1008 8.687 6.5 880 SKWLD1010 8.687 8.5 880 SKWLD1012 8.687 10.5 880 SKWLD1206 10.687 4.5 889 SKHHD6018 48 13.3 34 889 SKHHD6024 48 19.3 52 889 SKHHD7218 60 13.3 44 889 SKHHD7224 60 19.3 64 889 SKHHD7230 60 25.3 86 889 SKHHD7236 60 31.3 108 889 SKHHD9024 78 19.3 84 889 SKHHD9036 78 31.3 140SECTION A-ABAA ACSwing out panels for 9500 and 9412The 889 SKWHD & 889 SKHHD swing out panels are made of mild steel. Panels are hinged continuously on one side and are secured with quarter turn latches. Panels mount easily on channels provided in the cabinet. Finish is white heat fused powder paint, electrostatically applied on a pretreated base.CATALOG NUMBER A BDIMENSIONSA BDIMENSIONSA BDIMENSIONSComptatible with 9500, 9412 and 9412 DA.Comptatible with 5300 ESCH, 5412 ESCH, 5412 ESCHB, 5412 ESSCH, 5412 ESSPCH, 5412 EALCH, 5412 ESCHV, 5412 ESCHW, 5412 ESM, 5412 ESSM, 5412 ESSMP, 5412 ESSMPCH, 5412 ESSC, 5412 ESSSC, 5412 EALSC, 5412 ESLC, 5412 ESSLC and 5412 EALLCexmweb.com | 1-800-363-2423 | [email protected] with 9412, 9412 DD, 9412 SSDD, 9412 SS, 9500 DD, 9500 DAand 9500 DADD
