807TECHNICAL DATADATA SUBJECT TO CHANGE WITHOUT NOTICE.Table A-1CONVERSION OF NEMA ENCLOSURE TYPE RATINGS TO IEC 60529 ENCLOSURE CLASSIFICATION DESIGNATIONS ( IP) ( Cannot Be Used to Convert IEC Classification Designations to NEMA Type Ratings )IP FIRST CHARACTER NEMA Enclosure type IP SECOND CHARACTER1 23,3X, 3S, 3SX 3R, 3RX 4, 4X 5 6 6P12, 12K, 13IP0 IP_0IP1 IP_1IP2 IP_2IP3 IP_3IP4 IP_4IP5 IP_5IP6 IP_6IP_7IP_8A B A B A B A B A B A B A B A B A BA = A shaded block in the \for the respective IEC 60259 IP First Character Designation. The IP First Character Designation is the protection against access to hazardous parts and solid foreign objects. B = A shaded block in the \for the respective IEC 60259 IP Second Character Designation. The IP Second Character Designation is the protection against ingress of water.Referencing the first character, 4, in the IP rating and the row designated \_\ in the leftmost column in the table; the blocks in Column \3S, 3SX, 4, 4X, 5, 6, 6P, 12, 12K and 13 are shaded. These NEMA ratings meet and exceed the IEC protection requirements against access to hazardous parts and solid foreign objects. Referencing the second character, 5, in the IP rating and the row designated \_5\column in the table; the blocks in Column \3X, 3S, 3SX, 4, 4X, 6, and 6P are shaded. These NEMA ratings meet and exceed the IEC requirements for protection against the ingress of water. The absence of shading in Column \Enclosure Type 5: indicates that Type 5 does not meet the IP 45 protection requirements against an ingress of water. Likewise the absence of shading in Column \for NEMA type 12, 12K and 13 enclosures indicates that these enclosures do no meet the IP 45 requirements for protection against the ingress of water. Only Types 3, 3X 3S, 3SX, 4, 4X, 6, and 6P have both Column \the \_\ row and Column \the \_5\be used in an IP45 application. The NEMA Enclosure Type 3 not only meets the IP 45 Enclosure Rating, but also exceeds the IEC requirements because the NEMA Type requires an outdoor corrosion test; a gasket aging test; a dust test; an external icing test; and no water penetration in the rain test. Slight differences exist between the IEC and NEMA test methods, but the IEC rating permits the penetration of water if \does not deposit on insulation parts, or reach live parts.\rating does not require a corrosion test; gasket aging test; dust test or external icing test. Because the NEMA ratings include additional test requirements, this table cannot be used to select IP Designations for NEMA rating enclosure specifications. IEC 60529 specifies that an enclosure shall only be designated with a stated degree of protection indicated by the first characteristic numeral if it also complies with all lower degrees of protection. Furthermore IEC 60529 states that an enclosure shall only be designated with a degree of protection indicated by the second characteristic numeral if it also complies with all lower degrees of protection up to and including the second characteristic numeral 6. An enclosure designated with a second characteristic numeral 7 or 8 only is considered unsuitable for exposure to water jets (designated by second characteristic numeral 5 or 6) and need not comply with requirements for numeral 5 or 6 unless it is dual coded. Since the IEC protection requirements become more stringent with increasing IP character value up through 6, once a NEMA Type rating meets the requirements for an Ip designation up through 6, it will also meet the requirements for all lower IP designations. This is apparent from the shaded areas shown in the table. The NEMA and IEC comparison section is a re-work of an article from the National Electrical Manufacturers Association.EXAMPLE OF TABLE USE An IEC IP 45 Enclosure Rating is specified. What NEMA Type Enclosure meet and exceed the IP 45 rating?STANDARDS & CERTIFICATIONS
