Consoles

NEMA Rating RoHS CSA Underwriter Laboratories CE mark

Type 12, 13 | Writing desk for modular consoles with frontal access

6500 MWDFD
IP 54NEMA 12, 13Mild Steel painted RAL7035
Save
Remove From Saved List
Added to Saved List

See your favorite product on Saved List

View My Saved List Close
BoxCad Customize it here

The 6500 MWDFD series is used for indoor use and to protect the equipment against ingress of oil, dust, dirt and water. Use in conjunction with the 6500 MCOFD to create a console unit.

  • Made of high quality steel, with continuously welded corner seams.
  • The cover is secured by ¼ turn locks.
  • A robotically poured-in-place seamless gasket ensures a durable seal.
  • The enclosure has die cast hinges, with stainless steel captive pins.
  • The body’s construction is designed to prevent dripping water from entering the enclosure.
  • The enclosure is supplied with two gas springs.
  • Paint color: RAL7035 textured light gray.
  • CSA Certified.
  • UL Listed.
  • NEMA 12, 13.
  • IEC 60529 IP55.
Catalog Number Dimensions Ship Weight Downloads
A B C
6500 MWDFD0604 24 16 45 lbs 2D PDF | Zip Archive
6500 MWDFD0804 31 16 56 lbs 2D PDF | Zip Archive
6500 MWDFD1004 40 16 67 lbs 2D PDF | Zip Archive
6500 MWDFD1204 47 16 78 lbs 2D PDF | Zip Archive
6500 MWDFD1604 63 16 97 lbs 2D PDF | Zip Archive
