Disconnect

NEMA Rating RoHS CSA Underwriter Laboratories CE mark

Type 12, 13 | Double door freestanding cabinet for safety disconnect mounted on right flange

9500 U2D
IP 54NEMA 12, 13Mild Steel painted ASA 61 GrayDouble Door
Save
Remove From Saved List
Added to Saved List

See your favorite product on Saved List

View My Saved List Close
BoxCad Customize it here

The 9500 U2D series is used for indoor use and to protect the equipment against ingress of oil, dust, dirt and water.

  • Made of high quality steel, with continuously welded corner seams.
  • The doors are secured by padlockable 3 point lock mechanisms.
  • A system prevents the opening of the secondary door when the master door (right) is closed.
  • The enclosure has die cast hinges, with stainless steel captive pins.
  • The body’s construction is designed to prevent dripping water from entering the enclosure.
  • The center post is removable to facilitate the installation of the inner panel.
  • A bracket prevents the opening of the door when the electric circuit is not closed.
  • Paint color: ANSI 61 smooth gray.
  • CSA Certified.
  • UL Listed.
  • NEMA 12, 13.
  • IEC 60529 IP55.
Catalog Number Dimensions Ship Weight Downloads
A B C
9500 U2D725418 72 54 18 742 lbs 2D PDF | Zip Archive
9500 U2D726618 72 66 18 894 lbs 2D PDF | Zip Archive
9500 U2D727818 72 78 18 1027 lbs 2D PDF | Zip Archive
9500 U2D727824 72 78 24 1190 lbs 2D PDF | Zip Archive
9500 U2D847818 84 78 18 1110 lbs 2D PDF | Zip Archive
9500 U2D847824 84 78 24 1265 lbs 2D PDF | Zip Archive
9500 U2D907818 90 78 18 1196 lbs 2D PDF | Zip Archive
9500 U2D907820 90 78 20 1286 lbs 2D PDF | Zip Archive
9500 U2D907824 90 78 24 1343 lbs 2D PDF | Zip Archive
