The 5412 EALLC lift off cover, water oil and dust tight enclosures are used indoors or outdoors, in areas where the enclosures may be subjected to hosing or water coming from any direction. The box and cover are made of high quality 0.080” (Type 5052 H -32) aluminium, with all seams continuously welded. A high quality, robotically poured-in-place, seamless gasket ensures a complete and durable water tight seal.The opening has a curled lip around all sides to increase rigidity and prevent dripping water from entering when the door is open. A flange-mounted ¼ turn lock ensures positive closing. The enclosure can be internally or externally mounted using the included die cast wall mounting feet. Each enclosure comes complete with a 14 GA galvanized steel inner panel, which mounts on welded nuts. Enclosures are finished with heat fused powder paint, electro-statically applied on a pretreated base. Box is ANSI/ASA 61 smooth gray.
CSA Certified / UL Listed NEMA/EEMAC 4X / IP66
| Catalog Number | Dimensions | Ship Weight | Downloads | ||
|---|---|---|---|---|---|
| A | B | C | |||
| 5412 EALLC060403 | 6 | 4 | 3 | 2 lbs | 2D PDF | 3D File |
| 5412 EALLC060404 | 6 | 4 | 4 | 2 lbs | 2D PDF | 3D File |
| 5412 EALLC060604 | 6 | 6 | 4 | 3 lbs | 2D PDF | 3D File |
| 5412 EALLC080604 | 8 | 6 | 4 | 3 lbs | 2D PDF | 3D File |
| 5412 EALLC100804 | 10 | 8 | 4 | 5 lbs | 2D PDF | 3D File |
| 5412 EALLC121005 | 12 | 10 | 5 | 7 lbs | 2D PDF | 3D File |
| 5412 EALLC141206 | 14 | 12 | 6 | 10 lbs | 2D PDF | 3D File |
| 5412 EALLC141208 | 14 | 12 | 8 | 10 lbs | 2D PDF | 3D File |
| 5412 EALLC161406 | 16 | 14 | 6 | 12 lbs | 2D PDF | 3D File |
| 5412 EALLC161410 | 16 | 14 | 10 | 13 lbs | 2D PDF | 3D File |
